Height From Floor On Hanging Fire Extinguishers

The maximum reach to this equipment for example the fire extinguisher handle is 48 above the floor.

Height from floor on hanging fire extinguishers.

Mount fire extinguishers that weigh less than 40 pounds so the handle on top is no more than 5 feet above the floor. Larger fire extinguishers over 40 lbs. Osha fire extinguisher signage requirements. U0007 40 lbs or less install it so the top of the canister is no more than 5 ft above the floor.

Mount heavier extinguishers with the top handle no more than 3 5 feet above the. All hand portable fire extinguishers need to have at least 4 inches of clearance between their bottoms and the floor. However in osha s e tool for evacuation plans and procedures the agency states the following. Npfa 10 also sets specific conditions for the height of portable extinguisher installations see 1 6 10 for the full rundown.

Gross weight need to be mounted at lower heights with their carrying handles no more than 3 1 2 feet from the floor. U0007 more than 40 lbs install it so the top of it is no more than 3 5 ft above the floor. In the usa nfpa 1 requires portable fire extinguishers to be mounted with their top no more than 5 feet from the floor if under 40 pounds no more than 3 1 2 feet 42 inches if they are over 40. A fire extinguisher weighing less than 40 pounds like the extinguishers found in your home should be hung so that the top is not more than five feet above the ground but no lower than four inches above the floor according to the national fire protection association s standard for portable fire extinguishers nfpa 10.

Extinguishers with a gross weight greater than 40 pounds 18 14 kg except wheeled types should be installed so that the top of the extinguisher is not more than 3 feet 1 07 m above the floor. There is no height requirement listed. To prevent fire extinguishers from being moved or damaged they should be mounted on brackets or in wall cabinets with the carrying handle placed 3 1 2 to 5 feet above the floor. Larger fire extinguishers need to be mounted at lower heights with the carrying handle about 3 feet from the floor.

To prevent fire extinguishers from being moved or damaged. The actual mounting heights for cabinets housing this equipment can be determined by reviewing the exact dimensions of the specified cabinet and the positioning of the fire equipment within that cabinet.
